Review of Gem 550
Basic specs.
If you have a photo you would like to share: Upload Image
Looking for a new boat? Find a Gem 550 or similar boat for sale
The hull is made of fibreglass. Generally, a hull made of fibreglass requires only a minimum of maintenance during the sailing season. And outside the sailing season, just bottom cleaning and perhaps anti-fouling painting once a year - a few hours of work, that's all.
The Gem 550 is equipped with a fractional rig. A fractional rig has smaller headsails which make tacking easier, which is an advantage for cruisers and racers, of course. The downside is that having the wind from behind often requires a gennaker or a spinnaker for optimal speed.
Swing keel
The Gem 550 is equipped with a swing keel. A swing keel is a pivoting lifting keel, allowing to sail both coastal and inland waters.
The boat can sail close to the beach as the draft is just 0.23 - 0.33 meter (0.75 - 1.05 ft) dependent of the load. See immersion rate below.
Sailing characteristics
This section covers widely used rules of thumb to describe the sailing characteristics. Please note that even though the calculations are correct, the interpretation of the results might not be valid for extreme boats.
What is Capsize Screening Formula (CSF)?
The capsize screening value for Gem 550 is 3.02, indicating that this boat would not be accepted to participate in ocean races.
What is Theoretical Maximum Hull Speed?
The theoretical maximal speed of a displacement boat of this length is 5.5 knots. The term "Theoretical Maximum Hull Speed" is widely used even though a boat can sail faster. The term shall be interpreted as above the theoretical speed a great additional power is necessary for a small gain in speed.
The immersion rate is defined as the weight required to sink the boat a certain level.
The immersion rate for Gem 550 is about 82 kg/cm, alternatively 459 lbs/inch.
Meaning: if you load 82 kg cargo on the boat then it will sink 1 cm.
Alternatively, if you load 459 lbs cargo on the boat it will sink 1 inch.
Sailing statistics
This section is statistical comparison with similar boats of the same category. The basis of the following statistical computations is our unique database with more than 26,000 different boat types and 350,000 data points.
What is Motion Comfort Ratio (MCR)?
The Motion Comfort Ratio for Gem 550 is 6.6.
What is L/B (Length Beam Ratio)?
The l/b ratio for Gem 550 is 2.28.
The ballast ratio for Gem 550 is 35%.
What is Displacement Length Ratio?
The DL-ratio for Gem 550 is 110 which categorizes this boat among 'ultra light racers'.
SA/D (Sail Area Displacement ratio)
Indicates how fast the boat is in light wind:
- Cruising Boats have ratios 10-15
- Cruiser-Racers have ratios 16-20
- Racers have ratios above 20
- High-Performance Racers have ratios above 24
Sail-area/displacement ratio (SA/D ratio): 29.07
Maintenance
When buying anti-fouling bottom paint, it's nice to know how much to buy.
The surface of the wet bottom is about 13m2 (139 ft2).
Based on this, your favourite maritime shop can tell you the quantity you need.
Note: If you use a paint roller you will need more paint than if you use a paintbrush.
If you need to renew parts of your running rig and is not quite sure of the dimensions, you may find the estimates computed below useful.
| Usage | Length | Diameter | ||
| Jib sheet | 5.5 m | (18.0 feet) | 8 mm | (5/16 inch) |
| Genoa sheet | 5.5 m | (18.0 feet) | 8 mm | (5/16 inch) |
| Mainsheet | 13.8 m | (45.1 feet) | 8 mm | (5/16 inch) |
| Spinnaker sheet | 12.1 m | (39.7 feet) | 8 mm | (5/16 inch) |
