Review of Avance 24
Basic specs.
Looking for a new boat? Find an Avance 24 or similar boat for sale
Both the hull and the deck is made of fibreglass. Generally, a hull made of fibreglass requires only a minimum of maintenance during the sailing season. And outside the sailing season, just bottom cleaning and perhaps anti-fouling painting once a year - a few hours of work, that's all.
The boat is equipped with one cabin, 4 berths, a galley and toilet facility.
The Avance 24 is equipped with a fractional rig. A fractional rig has smaller headsails which make tacking easier, which is an advantage for cruisers and racers, of course. The downside is that having the wind from behind often requires a gennaker or a spinnaker for optimal speed.
Fin keel
The Avance 24 is equipped with a fin keel. The fin keel is the most common keel and provides splendid manoeuvrability. The downside is that it has less directional stability than a long keel.
The keel is made of iron. Many people prefer lead keel in favour of iron. The main argument is that lead is much heavier than iron and a lead keel can therefore be made smaller which again result in less wet surface, i.e. less drag. In fact iron is quite heavy, just 30% less heavy than lead, so the advantage of a lead keel is often overstated. As the surface of a fin type keel is just a fraction of the total wet surface, the difference between an iron keel and a lead keel can in reality be ignored for cruising yachts.
The boat can enter even shallow marinas as the draft is just about 1.45 - 1.55 meter (4.76 - 5.06 ft) dependent on the load. See immersion rate below.
An outboard motor is often used on this boat. In that case Avance 24 will typically require a power of 4 - 5 hp, alternatively 84 - 101 lbs thrust if you prefer an electrical motor. Electric outboards are becoming popular for sailboat owners who want clean instant power with less noise and no exhaust fumes.
Sailing characteristics
This section covers widely used rules of thumb to describe the sailing characteristics. Please note that even though the calculations are correct, the interpretation of the results might not be valid for extreme boats.
What is Capsize Screening Formula (CSF)?
The capsize screening value for Avance 24 is 2.07, indicating that this boat would not be accepted to participate in ocean races.
What is Theoretical Maximum Hull Speed?
The theoretical maximal speed of a displacement boat of this length is 5.9 knots. The term "Theoretical Maximum Hull Speed" is widely used even though a boat can sail faster. The term shall be interpreted as above the theoretical speed a great additional power is necessary for a small gain in speed.
The immersion rate is defined as the weight required to sink the boat a certain level.
The immersion rate for Avance 24 is about 102 kg/cm, alternatively 571 lbs/inch.
Meaning: if you load 102 kg cargo on the boat then it will sink 1 cm.
Alternatively, if you load 571 lbs cargo on the boat it will sink 1 inch.
Sailing statistics
This section is statistical comparison with similar boats of the same category. The basis of the following statistical computations is our unique database with more than 26,000 different boat types and 350,000 data points.
What is Motion Comfort Ratio (MCR)?
The Motion Comfort Ratio for Avance 24 is 18.1.
What is L/B (Length Beam Ratio)?
The l/b ratio for Avance 24 is 2.94.
The ballast ratio for Avance 24 is 45%.
What is Displacement Length Ratio?
The DL-ratio for Avance 24 is 245 which categorizes this boat among 'light crusers & offshore racers'.
What is SA/D (Sail Area Displacement ratio)?
The SA/D for Avance 24 with ISO 8666 reference sail is 14.6, with a 135% genua the SA/D is 17.2.
What is Relative Speed Performance?
The Relative Speed Performance for Avance 24 is 58
Maintenance
When buying anti-fouling bottom paint, it's nice to know how much to buy.
The surface of the wet bottom is about 18m2 (193 ft2).
Based on this, your favourite maritime shop can tell you the quantity you need.
Note: If you use a paint roller you will need more paint than if you use a paintbrush.
Dimensions of sail for fractional rig.
Are your sails worn out? You might find your next sail here: Sails for Sale
If you need to renew parts of your running rig and is not quite sure of the dimensions, you may find the estimates computed below useful.
| Usage | Length | Diameter | ||
| Mainsail halyard | 23.1 m | (75.6 feet) | 8 mm | (5/16 inch) |
| Jib/genoa halyard | 23.1 m | (75.6 feet) | 8 mm | (5/16 inch) |
| Spinnaker halyard | 23.1 m | (75.6 feet) | 8 mm | (5/16 inch) |
| Jib sheet | 7.5 m | (24.5 feet) | 10 mm | (3/8 inch) |
| Genoa sheet | 7.5 m | (24.5 feet) | 10 mm | (3/8 inch) |
| Mainsheet | 18.6 m | (61.2 feet) | 10 mm | (3/8 inch) |
| Spinnaker sheet | 16.4 m | (53.8 feet) | 10 mm | (3/8 inch) |
| Cunningham | 2.5 m | (8.2 feet) | 8 mm | (5/16 inch) |
| Kickingstrap | 5.0 m | (16.4 feet) | 8 mm | (5/16 inch) |
| Clew-outhaul | 5.0 m | (16.4 feet) | 8 mm | (5/16 inch) |
This section is reserved boat owner's modifications, improvements, etc. Here you might find (or contribute with) inspiration for your boat.
Do you have changes/improvements you would like to share? Upload a photo and describe what you have done.
We are always looking for new photos. If you can contribute with photos for Avance 24 it would be a great help.
If you have any comments to the review, improvement suggestions, or the like, feel free to contact us. Criticism helps us to improve.
