Review of Tartan 4600

Basic specs.

The Tartan 4600 is a large sailboat designed by the maritime architect Tim Jackett in the early nineties. The Tartan 4600 is built by the American yard Tartan Marine.

Here we would have liked to show you nice photos of the Tartan 4600.
If you have a photo you would like to share: Upload Image

Looking for a new boat? Find a Tartan 4600 or similar boat for sale

Hull

The hull is made of fibreglass. Generally, a hull made of fibreglass requires only a minimum of maintenance during the sailing season.

Rig

The Tartan 4600 is equipped with a masthead rig. The advantage of a masthead rig is its simplicity and the fact that a given sail area - compared with a fractional rig - can be carried lower and thus with less heeling moment.

Keel

The Tartan 4600 has been built with different keel alternatives.

Fin keel

One option is a fin keel. The fin keel is the most common keel and provides splendid manoeuvrability. The downside is that it has less directional stability than a long keel.

The boat can only enter major marinas as the draft is about 2.71 - 2.81 meter (8.89 - 9.19 ft) dependent on the load. See immersion rate below.

Fin keel

Another option is a fin keel. A boat with a fin keel is more manoeuvrable but has less directional stability than a similar boat with a full keel.

The boat can enter most marinas as the draft is just about 1.68 - 1.78 meter (5.51 - 5.81 ft) dependent on the load. See immersion rate below.

CentreBoard

Another option is a centreboard keel. A centreboard keel is a pivoting lifting keel, allowing to sail both coastal and inland waters.

Tartan 4600 can enter even shallow marinas as the draft is just about 1.46 - 1.56 meter (4.79 - 5.09 ft) dependent on the load. See immersion rate below.

Engine

The boat may be equipped with an inboard Westerbeke diesel engine at 63 hp (46 kW). Calculated max speed is about 6.9 knots

Sailing characteristics

This section covers widely used rules of thumb to describe the sailing characteristics. Please note that even though the calculations are correct, the interpretation of the results might not be valid for extreme boats.

Stability and Safety

What is Capsize Screening Formula (CSF)?

The capsize screening value for Tartan 4600 is 1.86, indicating that this boat could - if evaluated by this formula alone - be accepted to participate in ocean races.

Theoretical Maximum Hull Speed

What is Theoretical Maximum Hull Speed?

The theoretical maximal speed of a displacement boat of this length is 8.4 knots. The term "Theoretical Maximum Hull Speed" is widely used even though a boat can sail faster. The term shall be interpreted as above the theoretical speed a great additional power is necessary for a small gain in speed.

Immersion rate

The immersion rate is defined as the weight required to sink the boat a certain level. The immersion rate for Tartan 4600 is about 353 kg/cm, alternatively 1978 lbs/inch.
Meaning: if you load 353 kg cargo on the boat then it will sink 1 cm. Alternatively, if you load 1978 lbs cargo on the boat it will sink 1 inch.

Sailing statistics

This section is statistical comparison with similar boats of the same category. The basis of the following statistical computations is our unique database with more than 26,000 different boat types and 350,000 data points.

Motion Comfort Ratio

What is Motion Comfort Ratio (MCR)?

The Motion Comfort Ratio for Tartan 4600 is 30.9.

Comparing this ratio with similar sailboats show that it is more comfortable than 42% of all similar sailboat designs. This comfort value is just below average.

L/B (Length Beam Ratio)

What is L/B (Length Beam Ratio)?

The l/b ratio for Tartan 4600 is 3.22.

Compared with other similar sailboats it is more spacy than 73% of all other designs. It seems that the designer has chosen a slightly more spacy hull design.

Ballast Ratio

What is a Ballast Ratio?

The ballast ratio for Tartan 4600 is 30%.

This ballast ratio shows a righting moment that is higher than 24% of all similar sailboat designs. A righting moment (ability to resist heeling) significantly below average.

D/L (Displacement Length Ratio)

What is Displacement Length Ratio?

The DL-ratio for Tartan 4600 is 209 which categorizes this boat among 'light crusers & offshore racers'.

58% of all similar sailboat designs are categorized as heavier. A light displacement requires less sailarea and has higher accellerations.

SA/D (Sail Area Displacement ratio)

What is SA/D (Sail Area Displacement ratio)?

The SA/D for Tartan 4600 with ISO 8666 reference sail is 17.1, with a 135% genua the SA/D is 20.1.

The SA/D ratio indicates that it is faster than 27% of all similar sailboat designs in light wind.

Over- / underrigged

The Tartan 4600 has more rig than 42% of all similar sailboats, which indicates that the boat is slightly underrigged.

Maintenance

Bottom Paint

When buying anti-fouling bottom paint, it's nice to know how much to buy. The surface of the wet bottom is about 64m² (688 ft²).
Based on this, your favourite maritime shop can tell you the quantity you need.

Note: If you use a paint roller you will need more paint than if you use a paintbrush.

Rig

Dimensions of sail for masthead rig.

Are your sails worn out? You might find your next sail here: Sails for Sale

If you need to renew parts of your running rig and is not quite sure of the dimensions, you may find the estimates computed below useful.

**Guiding dimensions of running rig**
Usage	Length		Diameter
Mainsail halyard	42.1 m	(138.0 feet)	14 mm	(0.55 inch)
Jib/genoa halyard	42.1 m	(138.0 feet)	14 mm	(0.55 inch)
Spinnaker halyard	42.1 m	(138.0 feet)	14 mm	(0.55 inch)
Jib sheet	14.1 m	(46.2 feet)	16 mm	(5/8 inch)
Genoa sheet	14.1 m	(46.2 feet)	16 mm	(5/8 inch)
Mainsheet	35.2 m	(115.5 feet)	16 mm	(5/8 inch)
Spinnaker sheet	31.0 m	(101.6 feet)	16 mm	(5/8 inch)
Cunningham	5.8 m	(19.0 feet)	14 mm	(0.55 inch)
Kickingstrap	11.6 m	(38.0 feet)	14 mm	(0.55 inch)
Clew-outhaul	11.6 m	(38.0 feet)	14 mm	(0.55 inch)

Boat owner's ideas

This section is reserved boat owner's modifications, improvements, etc. Here you might find (or contribute with) inspiration for your boat.

Do you have changes/improvements you would like to share? Upload a photo and describe what you have done.

Finally

We are always looking for new photos. If you can contribute with photos for Tartan 4600 it would be a great help.

If you have any comments to the review, improvement suggestions, or the like, feel free to contact us. Criticism helps us to improve.

References

[Ref 1]: ISO 8666 Small craft — Principal data.
[Ref 3]: ISO 12215-5 Small craft — Hull construction and scantlings.
